TECHNICAL DETAILS
- Length X Width X Height2015×740×1090
- Wheelbase1385mm
- Seat height785mm
- Tank capacity15L
- Curb weight165
- Ground clearance118mm
- Engine typeInline 4-cylinder, DOHC, water-cooled, 4-stroke
- Displacement443cc
- Bore x stroke59×40.5
- Compression ratio12.9:1
- Max. power49kw/13250rpm
- Max. torque38N.m/11000rpm
- Max. speed220km/h
- Fuel supplyBOSCH EFI
- Max. speed220km/h
- Frame typeHC700+Q355B trellis frame
- Front suspensionKYB, φ41mm fully adjustable upside down front fork
- Rear suspensionKYB, fully adjustable, external airbag, rear shock absorber
- Suspension travelFront: 112mm/Rear: 40mm
- Front brakeDouble disc, opposed 4-piston calliper/ABS
- Rear brake220mm single disc, 1-piston calliper
- Front tire 120/70-17
- Rear tire160/60-17
- Steering angle28°
- Rake angle24.5°
- InstrumentionTFT
- OtherTCS, quick shifter, slipper clutch, RAM intake
