TECHNICAL DETAILS
- WORLDWIDE
- EU VERSION(35KW)
- EU VERSION(69.5KW)
- Length X Width X Height2230×930×1395mm
- Wheelbase1520mm
- Seat height826mm
- Tank capacity22L
- Curb weight215kg(with 3 cases)
- Ground clearance230mm
- Engine typeTwin cylinder, DOHC, 8 valves, water-cooled, 75° crankshaft
- Dispalcement799cc
- Bore x stroke88.0×65.7mm
- Compression ratio13：1
- Max. power71kW/9000rpm
- Max. torque80N.m/7500rpm
- Fuel supplyEFI
- Max. speed210km/h
- Power modeEco/Sport/Rain/Off road
- Frame typeDiamond shape, dual-wing beam, integrated chassis
- Front suspensionφ43mm Preload adjustable damping, KYB
- Rear suspensionPreload adjustable damping, KYB
- Suspension travel210/210
- Front brakeDual floating discs, single direction 2-piston floating calliper
- Rear brakeSingle disc, 1-piston floating calliper
- Front tire 110/80-R19 (CST)
- Rear tire150/70 R17 (CST)
- Steering angle35°
- Rake angle27.15°
- Instrumention7" TFT
- OthersQuick shifter, TCS, Cruise control, Heated seat and grip, Steering damping
- Length X Width X Height2230×930×1395mm
- Wheelbase1520mm
- Seat height826mm
- Tank capacity22L
- Curb weight215kg(with 3 cases)
- Ground clearance230mm
- Engine typeTwin cylinder, DOHC, 8 valves, water-cooled, 75° crankshaft
- Dispalcement799cc
- Bore x stroke88.0×65.7mm
- Compression ratio13：1
- Max. power35kW/7500rpm
- Max. torque66N.m/5000
- Fuel supplyEFI
- Max. speed155km/h
- Power modeEco/Sport/Rain/Off road
- Frame typeDiamond shape, dual-wing beam, integrated chassis
- Front suspensionφ43mm Preload adjustable damping, KYB
- Rear suspensionPreload adjustable damping, KYB
- Suspension travel210/210
- Front brakeDual floating discs, single direction 2-piston floating calliper
- Rear brakeSingle disc, 1-piston floating calliper
- Front tire 110/80-R19 （CST）
- Rear tire150/70 R17 (CST)
- Steering angle35°
- Rake angle27,15°
- InstrumentionQuick shifter, TCS, Cruise control, Heated seat and grip, Steering damping
- Length X Width X Height2230×930×1395mm
- Wheelbase1520mm
- Seat height826mm
- Tank capacity22L
- Curb weight215kg(with 3 cases)
- Ground clearance230mm
- Engine typeTwin cylinder, DOHC, 8 valves, water-cooled, 75° crankshaft
- Dispalcement799cc
- Bore x stroke88.0×65.7mm
- Compression ratio13：1
- Max. power69.5kW/9000rpm
- Max. torque79N.m/7500rpm
- Fuel supplyEFI
- Max. speed210km/h
- Power modeEco/Sport/Rain/Off road
- Frame typeDiamond shape, dual-wing beam, integrated chassis
- Front suspensionφ43mm Preload adjustable damping, KYB
- Rear suspensionPreload adjustable damping, KYB
- Suspension travel210/210
- Front brakeDual floating discs, single direction 2-piston floating calliper
- Rear brakeSingle disc, 1-piston floating calliper
- Front tire 110/80-R19 (CST)
- Rear tire150/70 R17 (CST)
- Steering angle35°
- Rake angle27,15°
- InstrumentionQuick shifter, TCS, Cruise control, Heated seat and grip, Steering damping
