TECHNICAL DETAILS
- Length X Width X Height1980×835×1075mm
- Wheelbase1370mm
- Seat Height790mm
- Tank Capacity13L
- Curb Weight153kg
- Ground Clearance150mm
- Engine Type Liquid cooled, inline dual cylinder, DOHC, 4 stroke, 8 Valves
- Displacement344cc
- Bore x Stroke69×46mm
- Max. power35KW @ 11500rpm
- Max. torque32.2N.m @ 9000rpm
- Compression Ratio12.5:1
- Max. speed180km/h
- Frame TypeDiamond shape, dual-wing beam, integrated
- Front SuspensionΦ41mm upside down hydraulic
- Rear SuspensionCentral monoshock hydraulic
- Front Brake320mm single disc, 2-piston floating calliper/ABS TAISKO
- Rear Brake220mm single disc, 1-piston floating calliper/ABS TAISKO
- Front Tire110/70 R17
- Rear Tire150/60 R17
- Steering Angle28°
- Rake Angle24.5°
