TECHNICAL DETAILS
- Length X Width X Height1980×835×1075mm
- Wheelbase1370mm
- Seat Height790mm
- Tank Capacity13L
- Curb Weight153kg
- Ground Clearance150mm
- Engine TypeLiquid cooled, inline dual cylinder, 4 stroke
- Displacement249cc
- Bore x Stroke62×41.4mm
- Max. power24KW @ 11500rpm
- Max. torque22.5N.m @ 9000rpm
- Compression Ratio12.5:1
- Max. speed145km/h
- Frame TypeDiamond shape, dual-wing beam, integrated
- Front SuspensionΦ37mm upside down damping, YUAN
- Rear SuspensionCentral monoshock damping, YUAN
- Front Brake320mm single disc, 2-piston calliper/ABS TAISKO
- Rear Brake220mm single disc, 1-piston calliper/ABS TAISKO
- Front Tire110/70 R17
- Rear Tire140/60 R17
- Steering Angle28°
- Rake Angle24.5°
