TECHNICAL DETAILS
- Length X Width X Height2000×745×1100mm
- Wheelbase1374mm
- Seat height790mm
- Tank capacity15L
- Curb weight164kg
- Ground clearance135mm
- Engine type Liquid cooled, inline dual cylinder, DOHC, 4 stroke, 8 valves
- Displacement344cc
- Bore x stroke69×46mm
- Compression ratio12.5:1
- Max. power35kW/11500rpm
- Max. torque32N.m/9000rpm
- Fuel supplyEFI
- Max. speed180km/h
- Front suspensionΦ37mm，unadjustable, upside down hydraulic
- Rear suspensionMonoshock damping, preload adjustable
- Suspension travelFront: 126mm/Rear: 45.5mm
- Front brakeΦ320mm, single fixed disc, 2-piston floating calliper
- Rear brakeΦ220mm, single fixed disc, 1-piston floating calliper
- Front tire 110/70 R17
- Rear tire150/60 R17
- Steering angle30°
- Rake angle24.5°
- InstrumentionTFT
