TECHNICAL DETAILS
- Length X Width X Height1975mm×743mm×1080mm
- Wheelbase1370mm
- Seat height790mm
- Tank capacity13L
- Curb weight153kg
- Ground clearance125mm
- Engine typeIn-line twin-cylinder/4-stroke/water-cooled
- Displacement249cc
- Bore x stroke62×41.4mm
- Compression ratio12.5:1
- Max. power24kW/11500rpm
- Max. torque22.5N·m/9000rpm
- Fuel supplyEFI
- Max. speed160km/h
- Front suspensionHydraulic front fork, upside down
- Rear suspensionMonoshock damping, preload adjustable
- Suspension travelFront 103.5mm/Rear 38.5mm
- Front brake320mm, single fixed disc, 2-piston calliper/ABS
- Rear brake220mm, single fixed disc, 1-piston calliper/ABS
- Front tire 110/70 R17
- Rear tire140/60 R17
- Steering angle31°
- Rake angle24.5°
- InstrumentionTFT
