500X EURO5

Color

Technical specs
  • Lux
  • Dimension
  • Engine
  • Chassis
  • Length X Width X Height2150×910×1450mm
  • Wheelbase1460mm
  • Seat height820mm
  • Tank capacity20L
  • Curb weight178kg
  • Ground clearance210mm
  • Trail106mm
  • Engine typeTwin cylinders, DOHC, water-cooled, 4 valves per cylinder
  • Displacement471cc
  • Bore x stroke67×66.8mm
  • Compression ratio10.7:1
  • Max. power35KW/8500rpm
  • Max. torque43N·m/7500rpm
  • Fuel supplyEFI
  • Max. speed170km/h
  • 0-100 km/h start acceleration6s
  • Fuel consumption4.2L/100km
  • Frame typeDiamond shape, dual-wing beam
  • Front suspension41mm KYB inverted fork Multi-adjustable
  • Rear suspensionAluminium swingarm with multi-adjustable KYB monoshock
  • Front brakeNISSIN, dual dics, 2-piston calliper/ABS
  • Rear brakeNISSIN, single disc, single piston calliper/ABS
  • Front tire Pirelli, 110/80 R19
  • Rear tirePirelli, 150/70 R17
  • Rake25.5°
  • InstrumentionLCD
Performance characteristics

Give you the best riding experience!

KYB shock absorber: it also help this model to maintain the stability. Powerful engine: the dual cylinder, vertical, DOHC water-cooled engine brings a maximum power of 35KW/8500rpm, a maximum torque of 43N·m/7500rpm, and a maximum speed of 170km/h. It has been sold in many countries and thousands units. Its quality and performance are confirmed by many riders all around the world.

Give you the best riding experience!

LCD instrument: it has improved the visibility of the interface and easy to use and look at. Self-made frame: that’s the reason why you can drive this model steadily. And this frame can overcome different road conditions because of the powerful toughness. Lightweight concept: the lightweight is always the concept of our brand. A lot of lightweight materials used on this model can give you a sporty and exhilarating ride on the turns.
